Category

Description

Unit

XG822FL

XG822FJ

Basic

Standard bucket capacity

m³

0.91

0.91

Basic

Operating Weight

t

21.5

21.5

Basic

Engine Brand

–

ISUZU

PERKINS

Basic

Engine Model

–

4HK1

1106D-70TA

Basic

Piston displacement

L

5.193

7.013

Basic

Maximum drawbar pull

Nm/rpm

657/1500

732/1400

Basic

Rated power/speed

kW/(r/min)

133/2000

129/2000

System Operating Pressure

Implement Circuits

MPa

34.3

31.4

System Operating Pressure

Swing Circuits

MPa

27.5

27.5

System Operating Pressure

Travel Circuits

MPa

34

34.3

System Operating Pressure

Maximum Rated Flow of main pumps

L/min

2×200

2×200

System Operating Pressure

Average Ground Pressure

Kpa

43

43

Working range

Boom

mm

5680

5680

Working range

Arm

mm

2910

2910

Working range

Maximum digging Radius

mm

9930

9910

Working range

Maximum Digging Depth

mm

6640

6670

Working range

Maximum Vertical digging depth

mm

6320

6050

Working range

Maximum digging height

mm

9600

9600

Working range

Maximum dumping height

mm

6800

6780

Working range

Max.excavating force (arm/bucket)

kN

107.5/150

99/137

Performance of the whole machine

Travel Speed (high/low)

km/h

5.0/3.0

5.1/3.2

Performance of the whole machine

Grading capacity

° / %

35°/70%

35°/70%

Performance of the whole machine

Max.traction

kN

205

185

Performance of the whole machine

Noises at driver location

dB(A)

75

76.5

Overall dimensions

Overall dimensions (L×W×H)

mm

9580×2990×2990

9500×2990×2920

Overall dimensions

Shoe width

mm

600

600

Overall dimensions

Minimum Foreside Swing Radius

mm

3560

3540

Overall dimensions

Minimum Tail Swing Radius

mm

2790

2830

Overall dimensions

Hydraulic Oil Filling Capacity/Hydraulic Oil Tank Capacity

L

230/320

230/320

Overall dimensions

Fuel Tank Capacity

L

380

350
