The TL150S Wheel Excavator is a powerful and versatile construction machine designed for excavation, loading, trenching, and material handling tasks. Built for efficiency and mobility, it combines strong hydraulic performance with a wheeled chassis, making it ideal for projects that require frequent movement between work sites.
Equipped with a reliable YUCHAI diesel engine and an advanced hydraulic system, the TL150S delivers excellent digging force, smooth operation, and high productivity. Its 360° rotation capability and robust digging reach make it suitable for road construction, urban infrastructure projects, utility works, and general construction applications. The wheeled design ensures faster travel speed and reduced surface damage compared to tracked excavators.
Category | Parameter | Specification |
Range of Operation | Boom length | 4200 mm |
Arm length | 2000 mm | |
Max. digging reach | 7450 mm | |
Max. digging depth | 4300 mm | |
Max. digging force | 60 kN | |
Max. digging height | 7670 mm | |
Max. dumping height | 5400 mm | |
Back-end radius of gyration | 2100 mm | |
Dimensions | Machine weight | 13,000 kg |
Transport dimensions (L × W × H) | 7250 × 2330 × 3040 mm | |
Axle base | 2600 mm | |
Ground clearance of counterweight | 1270 mm | |
Min. ground clearance | ≥ 440 mm | |
Technical Performance & Specification | Environmental standards | Country II |
Engine brand | YUCHAI | |
Rated power | 75 kW | |
Rated speed | 2200 r/min | |
Angle of rotation | 360° | |
Hydraulic system working pressure | 28 MPa | |
Hydraulic system flow | 230 L/min | |
Piston pump | 110 ml/r | |
Max. hauling force | 60 kN | |
Walking speed | 30 km/h | |
Grade climbing ability | 58% / 30° | |
Tyre model | 825-20 | |
Bucket capacity | 0.46 m³ | |
Swing overload pressure | 28 MPa | |
Fuel tank capacity | 200 L | |
Hydraulic oil tank capacity | 150 L |
